Hbs-Gq-20d Online Flying Laser Marking Engraving Machine

Laser Visibility : Visible

Trademark : HBS

Price : US $4,200-5,200 / P

Model NO. : HBS-GQ-20D

Origin : Beijing

Technical Class : Pulse Laser

Marking Method : Scanning Marking

Specification : 1200x880x380mm

Laser Wavelength : Fiber Laser

Laser Repetition Frequency : ≤100kHz

Cooling : Air Colling

HS Code : 8456301090

Applicable Material : Metal

Laser Classification : Solid Laser

Marking Speed : 12000mm/S

Transport Package : Cartons

Type : Optical Fiber Laser Marking Machine

Laser Source : Raycus

Cooling System : Air Cooling

Production Capacity : 200/Months

Marking Area : 110*110mm

MOQ : 1 Piece

Contact Now

Hbs-gq-20d Online Flying Laser Marking Engraving Machine

Product Descriptions:

With the pursuit of automation, intelligent laser line processing is commonly used in many factories. The principle of flying laser marking machine is the combination of galvanometer scanning and workpiece movement in the assembly line formed by the laser marking system, which is called the flight marking system.

The flying laser marking machine improves the efficiency of industry. Many factories have achieved automated production by using flying laser marking machine.

It has been widely used in food packaging, ci-garette lot number, mineral water production date, serial number, etc.

Exhibition:

Detailed Technical Information

Machine Model	HBS-GQ-20D
Laser Source	Raycus Advanced+
Average power	30 watts
Laser Power Lifetime	100,000 hours (Theoretical data)
Fiber cable length	2.5m
Cooling	Air cooling
Marking Wavelength	1064nm
Beam Quality	<1.5
Laser Repetition Frequency	≤100kHz
Marking Depth	0-1.5mm (adjustable with power setting, speed, materials)
Marking Speed	≤12000mm/s
Minimum Line Width	0.01mm
Minimum Character Size	0.05mm
Repetition Precision	±0.001mm
Standard Marking Area(mm)	110*110
Optional Marking Area(mm)	7575, 150150, 160160, 175175, 200200, 300300
Focal Length	Depends on marking area requirements
Power Consumption	≤500W
Machine Requirements	AC220V(±10%), 50Hz(±10%), 10A
Operation Temperature	-10ºC-60ºC
Humidity	5-95%
Control System	Win7, Win8, Win10, Win XP,
RAM	2GB-16GB
HDD	500G
Marking Formats	AI., PLT., DXF., TIFF., PNG., BMP., JPG. etc.
Computer Connection	2.0USB
Software	Ezcad 2.9.0

Optional Lens

Lens Type	HBS-65	HBS-110(Standard)	HBS-175
Focal Length	100mm	170mm	250mm
Marking Area	65mm*65mm	110mm*110mm	175mm*175mm
Note: HBS will provide lens with model HBS-200 for your company, marking area: 110mm*110mm

Packaging Details:

Package: 1200x880x380 mm

Company Info:

Beijing HBS Science & Technology Development Co., LTD is founded in 2001. HBS is specialized in developing and manufacturing laser marking machine with perfect quality and excellent after-sales services.

HBS had provided numerous well-known companies with wide range of solutions and reliable marking equipment, with strong and sustainable traceability.
